T-Motor F60A 3-8S 4-in-1 AM32 Mini ESC - 20x20

The T-Motor F60A 3-8S 4-in-1 AM32 Mini ESC is ready for micro or mini drones. Featuring AM32 firmware! It provides high current, high voltage tolerance, low internal resistance, and real-time temperature monitoring, ensuring no desync with high KV motors. Larger MOSFETs extend the ESC’s lifespan. Get in the air with T-Motor and the F60A AM32 Mini!

Check out all our 20x20 ESCs and all our T-Motor products!

Features

• AM32 Firmware

• Compact 20x20mm Mounting Pattern

• High Current and Voltage Tolerance

• Real-Time Temperature Monitoring

• No Desync with High KV Motors

• Low Internal Resistance

• 8S Voltage Support

• Large MOSFETs

Specifications

• PWM Frequency: 16KHz-96KHz (Default 24KHz)

• Mounting Holes: 20x20mm/4mm

• Dimensions: 36x47mm

• Amperage Scale: 200A

• Constant Current: 60A

• Input Voltage: 3-8S

• Burst Current: 70A

• Firmware: AM32

Includes

• 1x T-Motor F60A 3-8S 4-in-1 AM32 Mini ESC - 20x20

• 1x Amass XT60H-M Cable

• 1x FC Connector

• 10x Grommets

• 1x Capacitor
