SkyStarsRC Fly Stack H7 3-6S 30x30 Stack/Combo (H7 FC / KM60 32Bit 60A 4in1 ESC) - Dual Gyro

Check out our other 30x30 Stacks, and our SkystarsRC collection!

SkyStars H743 HD Flight Controller

• Input Voltage: 3-6S LiPo
• MCU: STM32H743VIT6, 480MHz, 1MB RAM, 2MB Flash
• Gyro: BMI270 Dual
• Baro: BMP280
• OSD:  Betaflight OSD
• UARTs: 8 Sets
• 8x PWM outputs
• 1x I2C
• 3x LEDs for FC STATUS (Blue, Green) and 3.3V indicator(Red)
• USB Type-C(USB2.0)
• 2x JST-SH1.0_8pin connector (Gnd/Vbat/S1/S2/S3/S4/Rx3/Curr)
• 1x JST-SH1.0_6pin connector (R1/G/R6/T6/G/10V)
• Dual Camera Inputs switch
• VTX 10V/Vbat filtered power ON/OFF switch
• DJI FPV OSD is supported by any spare UART
• Vbat Input: 7~25V (2~6S LiPo)
• BEC: 5V 2A Continuous (Max 3A)
• LDO 3.3V: Max 250mA
• Firmware: Betaflight - SKYSTARSH7HD
• Ardupilot : SKYSTARSH7HD

• Mounting: 30.5 x 30.5mm

• Dimensions: 39.5 x 39.5 x 7.8 mm

• Weight: 10.1g

SkyStars KM60 60A BLHeli_32 4-in-1 ESC - 30x30

• Continuous Current: 60A x4
• Burst Current: 80A x4
• Supports 3-6S battery
• Supports Dshot1200, Dshot600, Dshot300, PWM control signal
• ESC telemetry Supported

• No output BEC
• BLHeli_32 firmware
• Dimensions: 41x46
• Weight: 18g
• Mounting holes: 30.5x30.5 M3

Includes

• 1x SkyStarsRC 30x30 Fly Stack H7 Single Gyro FC / KM60 BLHeli-32 45A 3-6S
