Holybro Pixhawk 6X FC v2A Standard Set - ICM-45686

The Holybro Pixhawk Mini 6X FC Module v2A Standard Set is a compact, high-performance flight controller for advanced UAV applications. Featuring the ICM-45686 IMU sensor with BalancedGyro™ technology and a fast STM32H753 processor, it ensures precise, stable flight data and low-latency processing. Its modular design, advanced vibration isolation, and temperature-controlled IMU board provide reliable flight operations.

Check out our other wing flight controllers and the rest of our HolyBro selection!

Features

• Temperature-Controlled IMU Board

• Advanced Vibration Isolation

• High-Performance Processor

• Triple Redundancy Domains

• Modular Flight Controller

Specifications

PROCESSORS & SENSORS

• FMU Processor: STM32H753

  • 32-bit Arm® Cortex®-M7, 480 MHz, 2 MB flash memory, 1 MB RAM

• IO Processor: STM32F103

  • 32-bit Arm® Cortex®-M3, 72 MHz, 64 KB SRAM

• On-Board Sensors (Current Revision, Rev8):

  • Accel/Gyro: 3x ICM-45686 (with BalancedGyro™ Technology)

  • Barometer: ICP20100 & BMP388

  • Mag: BMM150

• On-Board Sensors (Previous Revision, Rev 3/4):

  • Security: NXP EdgeLock SE050 Plug & Trust hardware secure element

  • Accel/Gyro: BMI088 / ICM-20649

  • Accel/Gyro: ICM-42688-P

  • Accel/Gyro: ICM-42670-P

  • Barometer: 2x BMP388

  • Mag: BMM150

ELECTRICAL DATA

• Voltage Ratings:

  • USB Power Input: 4.75–5.25V

  • Servo Rail Input: 0–36V

  • Max Input Voltage: 6V

• Current Ratings:

  • Combined Output Current Limiter for All Other Ports: 1.5A

  • Telem1 Output Current Limiter: 1.5A

• PWM Signal Voltage:

  • Default: 3.3V (Adjustable to 5V with an onboard resistor change)

MECHANICAL DATA

• Dimensions:

  • Standard Baseboard: 52.4 x 102 x 16.7 mm (Aluminum)

  • Flight Controller Module: 38.8 x 31.8 x 16.8 mm

  • Mini Baseboard: 43.4 x 72.8 x 14.2 mm

• Weight:

  • Standard Baseboard: 72.5g (Aluminum)

  • Flight Controller Module: 31.3g

  • Mini Baseboard: 26.5g


For other technical information, please visit  https://docs.holybro.com/
Latest info on Supported Firmware
Power Module Setup Guide
Pixhawk Baseboards Ports
Sample Wiring Diagram
Full Specification
Dimensions
Downloads

Includes

• 1x Holybro Pixhawk 6X FC v2A Standard Set - ICM-45686

• 1x PM02D HV Power Module

• 1x Mini Baseboard

• 1x Cable Set
