HGLRC SPECTER F760 BOX 3-6S 20x20 Integrated Stack/Combo (F722 FC / 32Bit 60A 4in1 ESC)

In order to reduce the difficulty of installation to a large extent and allow model friends to easily get the fun of flying, we specially designed and developed the HGLRC SPECTER F760 BOX integrated stack. The flight control is a full module plug-in type, and only needs to weld the ESC power supply and motor wires. It is used, and the stack is equipped with suspended shock absorption and built-in capacitors. With the factory-preset filter parameters, the flight is even more outstanding!

Check out all our 20x20 stacks, and our HGLRC products!

Features

• The main control adopts STM32F722 high-performance processor, with a computing speed of up to 216MHz, providing smoother control, better hand feel, and faster response speed.
• The flight control gyroscope uses high-performance MPU6000 to improve the stability of use.
• Full module direct plug-in connection, plug and play, no soldering pads required, achieving modularity.
• Personalized CNC heat sink shell to prevent debris from entering the interior of the flight control and improve usage efficiency.
• 16MB large-capacity black box to ensure adequate recording of flight data.
• Integrated BF wireless Bluetooth parameter adjustment, connect to SpeedyBee APP to adjust serial port, PID and other flight control parameters anytime and anywhere.
• Equipped with a 10V electronic switch, the on/off mode can be set through BF, which is convenient for solving the problem of heat transmission during long-term power-on.
• Built-in suspension damping system + preset filter parameters.
• Built-in capacitor, no need to solder external capacitor.

Specifications

Flight Controller

• Flight control firmware: HGLRCF722 MINI V2
• MCU: STM32F722
• GYRO：MPU6000
• OSD: AT7456E
• Barometer: BMP280
• Black box: 16MB
• UARTS: 4
• Bluetooth parameter adjustment: UART5
• Input voltage: 7.4V-22.8V/2-6S LIPO
• BEC: 10V2A/5V2A
• Stack size: 37mmx34mmx9.8mm
• Installation hole position: 20x20mm, M3
• Weight: about 39.24g

ESC

• Input Voltage: 3-6S
• Continuous current: 60A
• Peak current: 60A (10 sec)
• MCU: STM32G071 (128K)
• Firmware: BL32(SPECTER60_G_128)
• ESC size: 44mmx36mmx7mm
• Mounting Hole: 20x20mm, M3
• Support Protocol: DShot600/300/150/Oneshot125/42, MultiShot

Includes

• 1x HGLRC SPECTER F760 BOX 3-6S 20x20 Integrated Stack/Combo (F722 FC / 32Bit 60A 4in1 ESC)
• 1x 30AWG 70mm single-head SH1.0-7P/single-head SH1.0-6P DJI cable
• 1x 30AWG 70mm single-head SH1.0-7P/single-head GH1.25-6P VTX cable
• 1x 30AWG 60mm single-head SH1.0-3P/single-head 1.25-3P camera cable
• 1x 30AWG 70mm single-head SH1.0-4P receiver cable
• 1x 30AWG 100mm, single-head SH1.0-4P LED soter cable
• 1x 30AWG 140mm single-head SH1.0-6P/single-head SH1.0-6P GPS cable
• 1x 14AWG 70mm, red and black power cord
• 5x M3x5 hexagon socket screws
• 5x M3x6 hexagon socket screws
• 5x M3x7 hexagon socket screws
