Flywoo GOKU Pro Mini Stack - F7 FC + 45A 2-6S AM32 4-in-1 ESC - ICM42688 - 20x20

83.99
        SPECIAL OFFER

          Please select all product options

          Product was out of stock

          share
          Description

          The Flywoo GOKU Pro Mini Stack is a high-performance 20x20mm stack. With an F7 flight controller and a 45A 2-6S AM32 4-in-1 ESC. Designed for precision and reliability, prepare for ultra-smooth flight performance and stability. The AM32 ESC supports DShot300, DShot600, and DShot1200, delivering responsive power. With a compact and lightweight design, this stack is perfect for micro and sub-250g builds. Check out the details below!

          Make sure to check out our other Stacks and the rest of our Flywoo selection.

          Features

          • High-Performance Processor
          • Large-Capacity Black Box
          • Multiple Motor Outputs
          • Stable Current Output
          • Precision Gyroscope
          • Durable Design
          Flywoo GOKU Pro Mini Stack - F7 FC + 45A 2-6S AM32 4-in-1 ESC - ICM42688 - 20x20

          Specifications

          FLIGHT CONTROLLER

          • BF Flight Controller Firmware: FLYWOO F722PROV2
          • Flight Controller Size: 32mm x 29mm x 20mm
          • INAV Firmware: FLYWOO F722PRO
          • Input Voltage: 7.4V - 26V / 2-6S LiPo
          • Mounting Holes: M2 20x20mm
          • Gyroscope: ICM42688
          • BEC: 10V 2A / 5V 2A
          • UARTs: 1, 2, 3, 4, 5, 6
          • Barometer: DP310
          • MCU: STM32F722
          • Black Box: 16MB
          • OSD: AT7456E
          • Weight: 9.9g

          ESC

          • Supports: Dshot300, Dshot600, Dshot1200
          • Firmware: GOKU_F4A32_PRO
          • PWM Frequency: 24k - 128k
          • Supports: AM32 Firmware
          • Continuous Current: 45A
          • Input Voltage: 2-6S LiPo

          Includes

          • 1x Flywoo GOKU G45M 45A 2-6S AM32 4-in-1 ESC - 20x20
          • 1x Flywoo GOKU Pro Mini F7 Flight Controller - ICM42688
          • 1 x Receiver Connection Cable
          • 1x  Camera Connection Cable
          • 1x FC&ESC Connection Cable
          • 5x  M3 Shock-Absorbing Ball
          • 5x  M2 Shock-Absorbing Ball
          • 1x Buzzer Connection Cable
          • 1x DJI O3 Connection Cable
          • 1x  GPS Connection Cable
