FlyFishRC M8QMC-5883L GPS & Compass Module (10th Gen)

37.49
        SPECIAL OFFER

          Please select all product options

          Product was out of stock

          share
          Description

          Check out the FlyfishRC-M10QMC! It is small, fast positioning, easy-to-use GPS. It adopts 18x18mm RHCP ceramic patch antenna that provides excellent reception capability and a highly stable connectivity. The built-in QMC5883L high-precision magnetometer provides precise azimuth pointing, and the u-blox10 generation chip allows subtle altitude changes to be skipped for more stability. Ideal for use with FPV drones, multi-rotors, fixed wing and other model products.

          Check out our GPS selection and all our FlyFishRC products!

          Features

          • 72 channel 10 Hz Refresh rate
          • Built-in TCXO crystal and farad capacitor for faster hot start
          • High sensitivity 18x18mm GPS patch antenna
          • SH1.0-6Pin terminal design, no soldering required
          • QMC5883L Magnetometer chip, precise pointing
          FlyFishRC M8QMC-5883L GPS & Compass Module (10th Gen)

          Specifications

          • GPS module: FlyFishRC M10QMC-5883L GPS Module
          • Frequencies: 72 channel
          • Refresh Rate: 10 Hz
          • Compass module: QMC5883L
          • Baud Rate:4800bps-115200bps (Default - 9600bps)
          • Sensitivity: Tracking: -162dBm, Capture: -160dBm,Cold Start:-148dBm
          • Accuracy: Horizontal <2.5m average), SBAS < 2.0m average, Timepulse: RMS 30 ns
          • Cold start: <24s
          • Hot start: <2s
          • Maximum height: 50000m
          • Maximum speed: 500 m/s
          • Speed accuracy: 0.05 m/s
          • Maximum acceleration: ≦ 4G
          • Input Voltage: 3.3V-5V,current 25mA
          • Output Connector: SH1.0-6P
          • Weight: 8.8g
          • GPS pin definition: RX/TX UART
          • Compass pin definition: SDA/SLA
          • GPS patch antenna size: 18 x 18 mm
          • Total dimensions:20 x 20 x 11 mm

          Includes

          • 1x FlyFishRC M10QMC GPS Module
          • 1x SH1.0-6 Pin Cable
          • 1x SH1.0 Connector
          • 1x GPS Manual
