Axisflying MANTA5 5 Freestyle True X Frame Kit

The AxisFlying MANTA series transforms freestyle frames with its innovative design and user-centric features. Crafted from precision CNC aluminum and premium carbon fiber, the MANTA5 offers unmatched durability, performance, and style, raising the bar in the freestyle community.

Check out our other 5' frames, and all our Axis Flying Products!

Features

• Innovative Freestyle Frame
• MANTA Series Innovation
• Optimized for Freestyle
• Durable Construction
• CNC Aluminum Parts
• User-Centric Design
• True X Configuration

Specifications

• Recommended Propellers: 4.9″-5.1″ freestyle propellers
• Recommended Motors: AF227, AF236, BlackBird V3
• Propeller Compatibility: Maximum 5.1-inch props
• Stack Mounting: 20*20mm,30.5*30.5mm
• VTX Mounting: 20*20mm, 30.5*30.5mm
• Motor Mounting Holes: 16x16mm (M3)
• Bottom to Top Distance: 25mm
• Bottom Plate Thickness: 3mm
• Top Plate Thickness: 2.5mm
• Material: T700 Carbon Fiber
• Lens Space: 14~20mm
• Arm Thickness: 5mm
• Wheelbase: 238mm
• Frame Type: True X
• Weight: 180g

Includes

• 1x Axisflying MANTA5 5' Freestyle True X Frame Kit
• 1x Hardware Kit
